Detailed Product Information
Product Description
LS710G diesel generator set, powered by the Cummins KTA38-G2B engine, delivers outstanding performance, reliability, and efficiency in high-demand power applications. Rated at 710kW (888kVA), this generator is engineered for industrial, commercial, and critical backup power systems.
Featuring advanced turbocharging technology, a durable design, and industry-leading support from Cummins, ensuring continuous power supply even in demanding environments. Whether for prime, standby, or emergency power, the LS710G is your trusted energy solution.
Main Features
- Powered by Cummins KTA38-G2B Engine – Rugged, high-horsepower diesel engine known for exceptional durability and fuel efficiency.
- High Output Capacity – Offers 710kW / 888kVA of power, ideal for large-scale facilities requiring stable, continuous electricity.
- Advanced Cooling & Turbocharging System – Efficient temperature control ensures optimal performance in various climates and high-load conditions.
- Heavy-Duty Alternator – Industrial-grade alternator provides consistent voltage output with excellent frequency stability.
- Robust Control Panel – Equipped with a digital controller for real-time monitoring, automatic start/stop, and fault alarms.
- Built for Harsh Environments – Suitable for oil & gas fields, mining, remote industrial zones, and high-altitude operations.
Generator Specification
| Generator Model | LS710G |
| Engine Model | KTA38-G2B |
| Rated speed | 1500rpm |
| Fuel Consumption(L/h) | 160 |
| Prime Power | 640KW/800KVA |
| Standby Power | 710KW/888KVA |
| Length(mm) | 4200 |
| Width(mm) | 1810 |
| Height(mm) | 2470 |
| Net Weight(kg) | 6500 |
Standard Generator Set List
| Generator Model | Engine Model | Standby Power | Prime Power | Speed | Fuel Consumption | ||
| kW | kVA | kW | kVA | rpm | L/h | ||
| LS36G | 4BT3.9-G2 | 36 | 45 | 32 | 40 | 1500 | 8 |
| LS140G | 6CTA8.3-G2 | 140 | 175 | 120 | 150 | 1500 | 30 |
| LS160G | 6CTA8.3-G2 | 160 | 200 | 140 | 175 | 1800 | 36 |
| LS220G | NT855-GA | 220 | 275 | 200 | 250 | 1500 | 41 |
| LS250G | NTA855-G1A | 250 | 313 | 220 | 275 | 1500 | 55 |
| LS280G | NTA855-G1 | 280 | 350 | 250 | 313 | 1800 | 61 |
| LS280G | MTAA11-G3 | 280 | 350 | 250 | 313 | 1500 | 61 |
| LS300G | NTA855-G1B | 300 | 375 | 275 | 344 | 1800 | 68 |
| LS300G | NTA855-G2A | 300 | 375 | 275 | 344 | 1500 | 68 |
| LS400G | KTA19-G2 | 400 | 500 | 360 | 450 | 1800 | 85 |
| LS400G | KTA19-G3 | 400 | 500 | 360 | 450 | 1500 | 85 |
| LS450G | KTA19-G3A | 450 | 563 | 400 | 500 | 1500 | 98 |
| LS450G | KTA19-G3 | 450 | 563 | 400 | 500 | 1800 | 98 |
| LS450G | KTA19-G4 | 450 | 563 | 400 | 500 | 1500 | 98 |
| LS550G | KTAA19-G5 | 550 | 688 | 470 | 588 | 1800 | 117 |
| LS660G | KTA38-G2 | 660 | 838 | 600 | 750 | 1500 | 147 |
| LS710G | KTA38-G2B | 710 | 888 | 640 | 800 | 1500 | 160 |
| LS880G | KTA38-G5 | 880 | 1100 | 800 | 1000 | 1500 | 200 |
| LS1100G | KTA50-G3 | 1100 | 1375 | 1000 | 1250 | 1500 | 245 |
| LS1100G | QSK38-G5 | 1150 | 1438 | 960 | 1200 | 1800 | 240 |
| LS1320G | KTA50-G8 | 1320 | 1650 | 1100 | 1375 | 1500 | 294 |
| LS1320G | KTA50-GS8 | 1320 | 1650 | 1200 | 1500 | 1500 | 300 |
