Product Description
Cummins KTA19-C600 is a genuine 18.9-liter inline-6 diesel engine engineered for heavy-duty mining applications. Delivering 600 HP rated power and up to 660 HP standby power, this engine combines high torque, reliability, and fuel efficiency to handle continuous operations under harsh mining conditions. Designed with Cummins’ proven technology, the KTA19-C600 ensures maximum uptime, reduced maintenance costs, and long-term operational success.
Cummins KTA19-C600 Engine Technical Specifications
| Item | Parameters |
| Engine Model | KTA19-C600 |
| Rated Power | 600 HP (447 kW) |
| Standby Power | 660 HP (492 kW) (optional depending on application) |
| Rated Speed | 1800 rpm |
| Engine Type | 4-stroke, water-cooled, inline 6-cylinder diesel engine |
| Bore × Stroke | 159 x 159 mm |
| Displacement | 18.9 L |
| Air Intake Method | Turbocharged and Aftercooled |
| Fuel System | PT fuel system (Pressure-Time injection system) |
| Compression Ratio | 14.5:1 |
| Cooling System | Closed water cooling system |
| Lubricating Oil Capacity | 50–56 L |
| Coolant Capacity (Including Radiator) | 57–63 L |
| Starting Method | Electric start (24V), optional air start on some configurations |
| Governing System | Electronic or mechanical governing (depending on configuration) |
| Emission Standard | Non-road machinery standard (e.g., China Stage II or Stage III non-road emission) |
| Dimensions (L×W×H) | 1700 × 1100 × 1500 mm |
| Net Weight | 1860–1950 kg (depending on specific configuration) |
Cummins KTA19-C Series Engine Core Parameter Comparison
| Parameter | KTA19-C450 | KTA19-C500 | KTA19-C525 | KTA19-C600 | KTA19-C700 |
| Rated Power (HP / kW) | 450 / 336 | 500 / 373 | 525 / 392 | 600 / 447 | 700 / 522 |
| Rated Speed (rpm) | 1800 | 1800 | 1800 | 1800 | 2100 |
| Engine Type | Inline 6-cylinder, 4-stroke | Inline 6-cylinder, 4-stroke | Inline 6-cylinder, 4-stroke | Inline 6-cylinder, 4-stroke | Inline 6-cylinder, 4-stroke |
| Bore × Stroke (mm) | 159 × 159 | 159 × 159 | 159 × 159 | 159 × 159 | 159 × 159 |
| Displacement (L) | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 |
| Air Intake Method | Turbocharged and Aftercooled | Turbocharged and Aftercooled | Turbocharged and Aftercooled | Turbocharged and Aftercooled | Dual turbocharged and aftercooled |
| Fuel System | PT fuel system | PT fuel system | PT fuel system | PT fuel system | PT fuel system |
| Compression Ratio | 14.5:1 | 14.5:1 | 14.5:1 | 14.5:1 | 14.5:1 |
| Cooling System | Closed water cooling | Closed water cooling | Closed water cooling | Closed water cooling | Closed water cooling |
| Lubricating Oil Capacity (L) | 50–56 | 50–56 | 50–56 | 50–56 | 50–56 |
| Coolant Capacity (L) | 57–63 | 57–63 | 57–63 | 57–63 | 57–63 |
| Starting Method | 24V electric start or air start | 24V electric start or air start | 24V electric start or air start | 24V electric start or air start | 24V electric start or air start |
| Net Weight (kg) | 1850 | 1860 | 1860 | 1950 | 1980 |
| Dimensions (mm) | 1700 × 1100 × 1500 | 1700 × 1100 × 1500 | 1700 × 1100 × 1500 | 1700 × 1100 × 1500 | 1700 × 1100 × 1500 |
Features & Benefits
- High Power & Torque – 600 HP rated (447 kW) and 660 HP standby (492 kW) with strong torque for demanding mining equipment.
- Durable Construction – 4-stroke, water-cooled, inline 6-cylinder design with reinforced cylinder block and forged components for long engine life.
- Advanced Cooling & Lubrication – Closed water cooling system with 57–63 L coolant capacity (including radiator) and 50–56 L lube oil capacity, ensuring stable performance under heavy load.
- Efficient Fuel System – Cummins PT (Pressure-Time) fuel injection system with turbocharging and aftercooling for precise combustion and improved fuel economy.
- Flexible Starting & Governing Options – 24V electric start (air start optional) and electronic or mechanical governing for adaptability across applications.
Typical Applications
- Medium to large mining haul trucks
- Hydraulic excavators and shovels
- Drill rigs and loaders
- Other heavy mining machinery requiring continuous, high-demand operation
